AWS Lambda MCP Cookbook - a Serverless MCP Server Blueprint¶

The Problem¶

Starting a Serverless MCP can be overwhelming. You need to figure out many questions and challenges that have nothing to do with your business domain:

• How to deploy to the cloud? What IAC framework do you choose?
• How to write a SaaS-oriented CI/CD pipeline? What does it need to contain?
• How do you handle observability, logging, tracing, metrics?
• How do you write a well-structured Lambda function?
• How do you handle testing?
• What makes an AWS Lambda handler resilient, traceable, and easy to maintain? How do you write such a code?

The Solution¶

This project aims to reduce cognitive load and answer these questions for you by providing an opinionated Python Serverless MCP server blueprint that implements best practices for AWS Lambda, MCP, Serverless CI/CD, and AWS CDK in one project.

This project is a blueprint for new Serverless MCP servers.

flowchart LR
    agents["MCP clients<br/>agents, IDEs"]
    waf["AWS WAF<br/>optional - see note"]
    gw["Amazon API Gateway<br/>HTTP API v2 · ANY proxy route"]

    subgraph fn["AWS Lambda · ARM64 · Python 3.14"]
        direction TB
        adapter["Lambda Web Adapter<br/>layer via AWS_LAMBDA_EXEC_WRAPPER"]
        uvi["uvicorn on :8000"]
        app["MCP server · mcp v2<br/>streamable_http_app at /mcp<br/>stateless_http · json_response"]
        adapter --> uvi --> app
    end

    ddb[("Amazon DynamoDB<br/>provisioned for app state")]
    cw["CloudWatch<br/>logs · metrics · dashboards · alarms"]
    xray["AWS X-Ray"]

    agents -->|"MCP over Streamable HTTP"| gw
    waf -.-> gw
    gw --> adapter
    app -.->|"unused by default"| ddb
    app --> cw
    app --> xray

    classDef optional stroke-dasharray: 5 5
    class waf,ddb optional

Serverless Lambda Web Adapter & the official MCP Python SDK¶

Based on AWS Web Adapter and the MCP Python SDK (mcp v2).

Use an HTTP API GW and Lambda function. Can be used with a REST API GW with a custom domain too.

The server is an ordinary ASGI (Starlette) app served by uvicorn behind the Lambda Web Adapter, so it upholds the official MCP protocol and has a native auth mechanism (OAuth).

Protocol versions¶

The SDK's streamable_http_app() serves both MCP protocol eras from the same endpoint, routed per request by the MCP-Protocol-Version header:

• 2026-07-28 - the current stateless spec: no initialize handshake, no Mcp-Session-Id.
• 2025-11-25 and earlier - the handshake era, for clients that have not migrated yet.

There is nothing to configure; both are always on.

Session data and DynamoDB¶

The 2026-07-28 protocol is stateless: there is no initialize handshake and no Mcp-Session-Id, and the server runs with stateless_http=True. Nothing is carried between requests for you.

That is a protocol change, not a restriction on your application. The stack still provisions a DynamoDB table and passes its name to the Lambda as TABLE_NAME, so you can use it to store session or conversation state whenever you want it. Nothing reads it out of the box - it is there for you to build on.

The lifespan yields a shared context object, and the table is resolved from TABLE_NAME on first use and reused thereafter - so the server still boots without any environment configured. A handler reaches it through the injected Context. The approach the spec recommends is a server-minted handle: your tool writes state to DynamoDB under a key it generates, returns that key to the client, and the client passes it back as an ordinary tool argument on the next call.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

from mcp.server.mcpserver import Context


@mcp.tool()
def start_analysis(dataset: str, ctx: Context) -> str:
    """Begin an analysis and return a handle to resume it."""
    handle = str(uuid.uuid4())
    ctx.request_context.lifespan_context.table.put_item(Item={'session_id': handle, 'dataset': dataset})
    return handle


@mcp.tool()
def continue_analysis(handle: str, ctx: Context) -> str:
    """Continue an analysis previously started with start_analysis."""
    state = ctx.request_context.lifespan_context.table.get_item(Key={'session_id': handle})['Item']
    ...

The table's partition key is session_id, and the Lambda role already grants GetItem, PutItem, UpdateItem and DeleteItem on it.

Monitoring Design¶

flowchart LR
    subgraph sources["Monitored resources"]
        direction TB
        gw["HTTP API Gateway"]
        fn["Lambda function"]
        logs["CloudWatch Logs<br/>ERROR pattern widget"]
        ddb[("DynamoDB table")]
        kpi["Custom metric<br/>ValidMcpEvents"]
    end

    subgraph high["High level dashboard"]
        direction TB
        h1["API Gateway health"]
        h2["Daily MCP Requests"]
    end

    subgraph low["Low level dashboard"]
        direction TB
        l1["Lambda latency, errors,<br/>throttles, invocations"]
        l2["Error log widget"]
        l3["DynamoDB usage, latency,<br/>errors, throttles"]
    end

    alarms["CloudWatch alarms<br/>5xx error rate · p90 latency"]
    sns["SNS topic<br/>KMS encrypted"]

    gw --> h1
    kpi --> h2
    fn --> l1
    logs --> l2
    ddb --> l3

    h1 --> alarms
    l1 --> alarms
    l2 --> alarms
    alarms --> sns

Features¶

• Python Serverless MCP server with a recommended file structure.
• Official MCP Python SDK v2 - supports the current 2026-07-28 spec and older clients alike.
• MCP Tools input validation: check argument types and values
• Tests - unit, integration (in-process MCP client against the real server) and E2E with a real MCP client
• CDK infrastructure with infrastructure tests and security tests.
• CI/CD pipelines based on Github actions that deploys to AWS with python linters, complexity checks and style formatters.
• CI/CD pipeline deploys to dev/staging and production environments with different gates between each environment
• Makefile for simple developer experience.
• The AWS Lambda handler embodies Serverless best practices and has all the bells and whistles for a well-structured handler.
• AWS Lambda handler uses AWS Lambda Powertools.
• AWS Lambda handler 3 layer architecture: handler layer, logic layer and data access layer
• CloudWatch dashboards - High level and low level including CloudWatch alarms

The GitHub blueprint project can be found at https://github.com/ran-isenberg/aws-lambda-mcp-cookbook.

Serverless Best Practices¶

The AWS Lambda handler will implement multiple best practice utilities.

Each utility is implemented when a new blog post is published about that utility.

The utilities cover multiple aspects of a well-structured service, including:

• Logging
• Observability: Monitoring and Tracing
• Observability: Business KPI Metrics
• Environment Variables
• Hexagonal Architecture
• Input Validation
• Serverless Monitoring
• Learn How to Write AWS Lambda Functions with Three Architecture Layers

While the code examples are written in Python, the principles are valid to any supported AWS Lambda handler programming language.

Security¶

• Use the SDK's auth parameter on MCPServer for an OAuth implementation, or put an IAM/Cognito/Lambda authorizer in front of the API Gateway.
• DNS rebinding protection is switched off in service/app.py. That check exists to protect a server bound to a local port from browsers on the same machine; under the Lambda Web Adapter the app only listens on loopback inside the execution environment and API Gateway forwards its own Host header, so leaving it on would reject every request with 421 Misdirected Request. API Gateway is where authn/authz belongs here.

Known Issues¶

• There might be security issues with this implementation, MCP is very new and has many issues.

Handler Example¶

The MCP surface is split by capability kind, mirroring the business logic layout so each protocol binding sits opposite the logic it exposes:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

service/
  app.py                     the ASGI app uvicorn serves - assembles everything below
  mcp_app/
    mcp_server.py            the MCPServer instance, its identity and instructions
    caching.py               cache hints advertised on catalog listings
    context.py               AppContext + lifespan (shared, per-process state)
    handlers/
      __init__.py            imports the modules below - this is what registers them
      tools.py               -> service/logic/math.py
      resources.py           -> service/logic/profiles.py
      prompts.py             -> service/logic/hld.py

A handler binds the protocol to a logic function and declares how clients may treat it:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21

"""MCP tools. Business logic lives in `service.logic.math`."""

from mcp.types import ToolAnnotations

from service.handlers.utils.observability import logger
from service.logic.math import add_two_numbers
from service.mcp_app.mcp_server import mcp


@mcp.tool(
    title='Add two numbers',
    annotations=ToolAnnotations(
        read_only_hint=True,  # touches no state, so clients may auto-approve it
        idempotent_hint=True,  # same arguments always produce the same answer
        open_world_hint=False,  # pure computation, no external systems
    ),
)
def math(a: int, b: int) -> int:
    """Add two numbers together"""
    logger.info('using math tool', extra={'a': a, 'b': b})
    return add_two_numbers(a, b)

The server object is built once, with its identity, lifespan and cache hints:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47

"""The MCP server object and its identity.

Importing this module gives you a server with **no capabilities registered**. The tools, resources
and prompts live in `service.mcp_app.handlers` and register themselves on import - see that
package's docstring. Import `service.app` if you want the fully assembled server.
"""

from mcp.server import MCPServer

from service.mcp_app.caching import CACHE_HINTS
from service.mcp_app.context import lifespan

SERVER_INSTRUCTIONS = """\
A sample serverless MCP server. Use the 'math' tool to add two integers. Read
'users://{user_id}/profile' to look up a user by numeric id. Use the
'generate_serverless_design_prompt' prompt to turn a set of requirements into a serverless
high level design brief."""


class DeterministicMCPServer(MCPServer):
    """Serves the catalog in a stable, name-sorted order.

    The 2026-07-28 spec asks servers to list in a deterministic order so clients can cache the
    result and LLM prompt caches keep hitting. Registration order is already stable per
    deployment; sorting keeps it stable even as capabilities are added or moved between modules.
    """

    async def list_tools(self):
        return sorted(await super().list_tools(), key=lambda tool: tool.name)

    async def list_prompts(self):
        return sorted(await super().list_prompts(), key=lambda prompt: prompt.name)

    async def list_resource_templates(self):
        return sorted(await super().list_resource_templates(), key=lambda template: template.name)


mcp: MCPServer = DeterministicMCPServer(
    name='mcp-lambda-server',
    title='AWS Lambda MCP Cookbook',
    description='serverless MCP server blueprint.',
    instructions=SERVER_INSTRUCTIONS,
    website_url='https://github.com/ran-isenberg/aws-lambda-mcp-cookbook',
    version='4.0.0',
    lifespan=lifespan,
    cache_hints=CACHE_HINTS,
)

And the entrypoint pulls in the handlers and exposes the ASGI app:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

"""The ASGI app. `run.sh` serves this module's `app` with uvicorn behind the Lambda Web Adapter.

Importing this module assembles the whole server: `mcp` comes from `service.mcp_app.mcp_server`
and importing `handlers` runs the decorators that register every capability on it. The dependency
runs one way - app -> handlers -> mcp_server - so nothing here needs a deferred import.
"""

from mcp.server.transport_security import TransportSecuritySettings

from service.mcp_app import handlers  # noqa: F401  - imported for its registration side effect
from service.mcp_app.mcp_server import mcp

# DNS rebinding protection guards a server that binds a local port against browsers on the same
# machine. Under the Lambda Web Adapter the app only ever listens on loopback inside the execution
# environment, and the public edge is API Gateway - which forwards its own Host header. Leaving the
# default on would reject every request with 421 Misdirected Request, so it is turned off here and
# the edge is where authn/authz belongs.
app = mcp.streamable_http_app(
    stateless_http=True,
    json_response=True,
    transport_security=TransportSecuritySettings(enable_dns_rebinding_protection=False),
)

License¶

This library is licensed under the MIT License. See the LICENSE file.
